Merillat Drawer Guide Adapter

This item has been discontinued and is no longer in stock.

** Cabinet Replacement Drawer Guides with Cabinet Adapters
(located below) are the new replacement option. **


OUT OF STOCK
NOT AVAILABLE

drawer sliders

Replacement Drawer Guides with cabinet adapter
for Merillat Kitchen and Bathroom Cabinets

One pair (right and left) of cabinet-mounted guides with adapters for Merillat cabinets. These can be used on most Merillat cabinets. Only available in white.
Standard kitchen guides are 23-5/8" for 24" deep cabinets.
Standard bathroom guides are 20-5/8" for 21" deep cabinets.
Space-saver bathroom guides are 17-5/8" for 18" deep cabinets.
(Drawer-box mounted components are available by calling us)

$14.95 /pair
Only available in white

Base Tray Kit

Merillat Roll Out Trays

Available for 12" to 45" wide cabinets made from 2000-current.
Installs at the bottom or middle of Merillat base cabinets utilizing pre-drilled holes in back panel & some face frames. One tray per kit. Includes tray core box & left & right roller guides along with installation hardware. Tray front made of solid hardwood. Tray sides, back & bottom made of engineered wood covered with moisture & stain resistant, easy clean laminate


$43.00
Select Tray width and finish:
Merillat Double Deep Base Tray Kit

Merillat Double Deep Roll Out
Base Tray Kit


Available for 12" to 45" wide cabinets made from 2000-current.
Installs at the bottom or middle of Merillat base/utility cabinets utilizing pre-drilled holes in back panel & some face frames. Includes tray core box & left & right roller guides along with installation hardware. Trays are made of solid 1/2" thick hardwood with dovetail joints. Bottoms are 1/4" thick wood grained printed plywood.


$52.00
Natural Maple Finish only.

Select Tray width:


5/8" replacement shelf clip/bracket

Replacement Shelf Clip/Bracket for 3/4" thick shelf

Replacement shelf clip with 5mm post for 3/4" shelf
For Merillat Cabinets built in 2000 or newer.

$0.29
Clear

Replacement Shelf Clip/Bracket for 5/8" thick shelf

Replacement shelf clip with 1/4" post for 5/8" shelf
For Merillat Cabinets built in 1999 or older.

$0.29
Clear

Drawer Organizer

Drawer Organizer / Cutlery Tray

14-5/8" x 22" x 2-1/4". Each section is 2-5/8" wide.
Use in 15" wide drawer or cut to fit.
Minimum trim depth is 15-3/4"

$44.95
Hard Maple


18" Double Waste Basket Roll Out

18" Double Waste Basket Roll Out

35-Quart Double Pull-Out Waste Container System.
14-1/2" x 22" Full Extension Ball Bearing Slides.
Heavy Duty Wire Construction. Designed for use with 13 gallon tall kitchen trash bags. Mounts to Floor of Cabinet. Door Mountable in photo (kit sold separately).
Mounting Hardware and Instructions Included.
For standard 18" cabinets.

$82.95
Finish

15" Single Waste Basket Roll Out

15" Single Garbage Roll Out

35-Quart Single Pull-Out Waste Container System.
10-1/4" x 22" Full Extension Ball Bearing Slides.
Heavy Duty Wire Construction. Designed for use with 13 gallon tall kitchen trash bags. Mounts to Floor of Cabinet.
Door Mountable (kit sold separately).
Mounting Hardware and Instructions Included.
For standard 15" cabinets.


$62.17
Finish

Cabinet Door Mounting Kit

Cabinet Door Mounting Kit

For use with single and double pull-out waste container system (sold separately). Mounting Hardware and Instructions Included.

$11.99
Finish

Blind Corner Roll Out - for blind corner cabinets 42/45

Base Blind Corner Cabinet
Lazy Susan roll out

For use in blind corner cabinets BBC42/45
Designed to support up to 38 pounds of canned goods per shelf.
Requires a minimum cabinet opening of 13 1/4".
Overall shelf dimensions 31 9/16" X 12 1/2"
available in white or almond color

$153.14
Finish

Blind Corner Roll Out - for blind corner cabinets 42/45

Base Blind Corner Cabinet
Lazy Susan roll out

For use in blind corner cabinets BBC45/48
Designed to support up to 45 pounds of canned goods per shelf.
Requires a minimum cabinet opening of 16 1/16".
Overall shelf dimensions 33" X 15 1/2"
available in white or almond color

$164.87
Finish

under sink tote

Merillat Under Sink Tote

Designed for under sink storage, maximizes space around plumbing fixtures.
White epoxy-coated wire baskets. 3/4 roll-out assembly mounts to the floor of the cabinet. Overall dimensions 12" wide x 18 25/32" deep x 15 1/4" high.
Top basket is removable.
For use on a Kitchen Sink Base cabinet 33" or smaller in width.
Load rating of 20 pounds.


$74.97
White Finish


under sink tote

Merillat Under Sink Tote

Designed for under sink storage, maximizes space around plumbing fixtures. White epoxy-coated wire baskets. 3/4 roll-out assembly mounts to the floor of the cabinet. Overall dimensions 12" wide x 18 25/32" deep x 15 1/4" high.
Top basket is removable.
For use on a Kitchen Sink Base cabinet 36" or larger in width.
Load rating of 20 pounds.


$83.47
White Finish



tip out sink tray

11-11/16" Wide Sink Tilt-Out Tray Set.

White Plastic. 2" Deep x 3" Tall.
Includes two trays, two sets of hinges and 20pcs screws.

$21.25
White Finish


tip out sink tray

14-13/16" Wide Sink Tilt-Out Tray Set.

White Plastic. 2" Deep x 3" Tall.
Includes two trays, two sets of hinges and 20pcs screws.

$21.25
White Finish
